CH3LR
Novidade
OPTIONS:
OPTIONS:
REF: 243900005
Frame:
- Towed models from 5.00 m and 6.00 m working width.
- All the models are composed by one central section in tube 300x300x10 mm, which supports 2 side sections in tube of 100x100x10 mm where the tines are mounted.
- Hydraulic drawbar CAT. IV or V, with a hydraulic adjustment system, allows to adjust the working depth.
Tines:
- Opening system guaranteed by 4 hydraulic cylinders.
- Special treated steel Hardox 450 tines, with 30 mm thickness.
- Nonstop system by double compression springs with tension adjuster.
Wear:
- Equipped with points, deflectors and shares.
- Plain or notched levelling discs of 450 mm diameter.
- Working depth: 0.35 m.
Space between teeth:
- Underbeam clearance: 0.85 m.
- Underbeam between lines (810 mm) and the soil (850 mm), working with a rear roller, to ensure the good performance of the equipment.
Depth adjustment wheel:
- Frontal stabiliser wheels with height adjustment, through hydraulic cylinder.
